Description
- Require fixed inlet pressure.
- Aluminium (matt chrome-plated) body.
- ABS regulation control knob.
- Brass (matt chrome-plated) DISS outlet.
- Latex-free.
Optional accessories: consult brochure.
|
Dimensions (Width x Height) |
37 x 56 mm |
|
Weight |
98 g |
|
Gas options |
O2 and Air |
|
Fittings |
BS, NF, DIN and SS For other fittings, please consult |
|
Without fitting (Whitworth thread G1/8” F) |
|
|
Outlet fitting |
DISS O2 9/16” – 18h UNF |
|
DISS connector for O2 and Air hose |
|
|
Inlet pressure |
P4 4 bar = 400 kPa |
|
P5 50 psi = 345 kPa |
|
|
Accuracy |
±10% |
|
Flow settings (L/min)
|
P4-P5 OX1 0 – 0.1 – 0.15 – 0.2 – 0.25 – 0.3 – 0.35 – 0.4 – 0.5 – 0.6 – 0.7 – 0.8 – 0.9 – 1 |
|
P4-P5 OX5 0 – 0.1 – 0.2 – 0.3 – 0.4 – 0.6 – 0.8 – 1 – 1.5 – 2 – 2.5 – 3 – 4 – 5 |
|
|
P4-P5 OX15 /AIR15 0 – 0.2 – 0.5 – 0.7 – 1 – 1.5 – 2 – 3 – 4 – 5 – 7 – 10 – 12 – 15 |
|
|
P4-P5 OX50 / AIR50 0 – 1 – 3 – 5 – 7 – 10 – 15 – 20 – 25 – 30 – 35 – 40 – 45 – 50 |
|
|
Option |
Rail coupling |
